Converter Smart A1 Connect
The smart wireless solution for industrial and commercial energy metering
The A1 Connect reads measurement data via the AMR interface and wirelessly transmits it via LoRaWAN or NB-IoT to a cloud platform or energy management system. This provides grid operators, energy suppliers, and energy professionals with real-time insights into energy consumption and electrical infrastructure quality.
Data Integration via MQTT
The Smart A1 Connect supports standard MQTT, a lightweight and efficient protocol ideal for communication with cloud applications, IoT platforms, and energy management systems. This enables seamless integration of energy data into professional software solutions for energy monitoring and reporting. You can also link the dongle to an external MQTT broker via the web interface. Xemex also offers integration with the ENNY platform, hosted in Europe, with secure MQTT communication and optional cloud analytics.
Hardware/software interface – no hosting required
The dongle combines hardware and embedded software to act as a reliable translator — not a server or host. It does not run services like a broker itself but provides clean, secure access to your meter data.
Difference with Smart P1 Connect
While the Smart P1 Connect is designed for households and small business applications with a standard P1 interface, the Smart A1 Connect targets large-scale installations with an AMR interface. The A1 offers greater flexibility, reliability, and scalability for environments where energy is a critical business factor.
- Connectivity: LoRaWAN 1.0.3 (Class A & C), NB-IoT (LTE Cat NB1/NB2), MQTT protocol for cloud/EMS integration, Modbus TCP optional (not standard).
- Meter Interface: Connection via A1/AMR interface, compatible with high-consumption meters according to DSMR, EBZ, SML, or IEC specifications, supports meters from Fluvius, Sibelga, Enedis, and Ores, real-time reading of active/reactive consumption, voltage, peak power, feed-in, and voltage quality.
- Power Supply: External power required, USB-C (5V) or industrial power supply, energy-efficient operation via smart protocol configuration.
- Mounting and Form Factor: Compact IP20 enclosure, plug & play installation, suitable for wall mounting or DIN rail (with optional adapter).
- Data Functionality: Configurable periodic measurement intervals (standard 5–15 minutes), wireless data forwarding via MQTT, buffer memory for temporary storage during connection loss, over-the-air firmware updates (FOTA).
- Environmental Specifications: Operating temperature: -10 °C to +55 °C, CE certified, low power consumption (optimized for battery-powered meters).
- Consumption Monitoring
Companies, government bodies, and industrial sites often have multiple metering points spread across various locations. With the Smart A1 Connect, these meters can be centrally read via the AMR interface without relying on local networks. Consumption data is automatically forwarded to a platform or EMS. This real-time insight enables targeted measures for energy savings, cost reduction, and sustainability reporting. - Load Management in Industrial Installations
In industrial environments, managing power consumption is critical. The A1 Connect provides frequent measurement data that companies can use to align consumption with grid capacity and internal processes. This helps prevent exceeding contracted power, contributing to grid stability and cost efficiency. - Energy Monitoring in Multi-Tenant Buildings
In buildings with multiple tenants (e.g., business parks or retail centers), it is important to have clear consumption insights per tenant or zone. With AMR meters on different connections, the A1 Connect can easily monitor each part of the building separately. Data is wirelessly sent to a platform where managers and tenants can view their own consumption. - Integration with Solar Installations and EMS
Many companies combine their infrastructure with solar panels, battery storage, or heat pumps. The Smart A1 Connect allows mapping and integration of these energy flows into an energy management system. By combining production and consumption data, a complete energy profile emerges, essential for optimization and sustainability.
Converter Smart A1 Connect
The Xemex Smart A1 Connect makes it easy to read smart meters: Ideal for EV charging station installations with load balancing.
Availability
- In stock
Get informed about this product
Questions about our products? Contact Xemex and discuss your needs with our team. Together we will realize a solution that addresses your energy challenges and opens up new possibilities. Need manuals, manuals and datasheets? Please contact our Support department
